Specification
Specifications
- Product codeFTC21-ups
- Suggested price$99.00
- Switch chip model88E6341
- Tested ambient temperature-40°C to 70°C
- Tested ambient temperature-40°C to 70°C
- MTBFApproximately 100'000 hours at 25C
- Tested ambient temperature-40°C to 70°C
Powering
- Number of DC inputs2 (DC jack, PoE-IN)
- DC jack input Voltage24-57 V
- Max power consumption28 W
- Max power consumption without attachments3 W
- PoE in802.3af/at
- Cooling typePassive
- PoE in input Voltage48-57 V
PoE-out
- PoE-out portsEther2
- PoE outPassive PoE up to 57V
- Low voltage PoE-Out current limit0.625 A
- High voltage PoE-Out current limit0.315 A
- Max total out (A)0.625 A
- Total output current0.625
- Total output power15
Ethernet
- 10/100/1000 Ethernet ports2
- Number of 1G Ethernet ports with PoE-out1
Fiber
- SFP ports1 (2.5G supported)
Other
- PCB temperature monitorYes
Certification & Approvals
- CertificationCE, EAC, ROHS
- IP67
Included parts
K-95 kit
48 V 0.95 A power adapter
Gigabit PoE injector
Hose clamp 1
Note
The device has an operating system preinstalled and licensed. No separate purchase is necessary and the product is ready to use. The device includes free software updates for the life of the product or a minimum of 5 years starting from date of purchase.
