| System |
|---|
| Main Processor | Intel Quad Core @3.40 GHz Max |
| Memory | 4GB LPDDR5 |
| Firmware Storage | 32GB eMMC |
| Operating System | Linux Ubuntu 24.04 LTS |
| GPU Options | Integrated GPU |
| TPM | fTPM |
| Auto Power On | Support |
| Storage |
| Supported SSD | Max. 8TB, up to 4TB per disk |
| SSD Slot | 2* M.2 M-Key SSD |
| Network |
| Protocol | IPv4, IPv6, TCP/IP, UDP/IP, RTP (UDP), RTP (TCP), RTSP, NTP, HTTP, DHCP (Client), ICMP, IGMP, ARP, DNS, HTTPS, ONVIF, NFS, SMB |
| Audio |
| Compression | G.711/AAC/G.726 |
| Audio Communication | 2-way |
| Performance |
| Video Inputs | Max. 16CH |
| Video Resolution | 12MP ~ CIF |
| Network Bandwidth | Max. 140Mbps Recording, Max. 140Mbps Outgoing |
| Metadata Performance | 32 targets/s (AI by Camera) |
| Video Compression | H.265, H.264, MJPEG |
| Decoding Capability | Support Hardware Decoding |
| Storage Mode | Continuous, Motion, Events, Objects, Dual Stream |
| Edge Analytics | Analytics Events (Based on camera metadata):
CCTV (Intrusion Detection/ Region Entrance/ Region Exit/ Advanced Motion Detection/ Line Crossing/ Loitering/ Object Left/Object Removed/ Object Counting/ Regional People Counting);
LPR (Attribute Event/ Black List/ White List/ Visitor Event/ Speed Monitoring/ No Plates/ Reverse Driving); Object Detected Events (Person and Vehicle with Attribute/ Face)
Smart Search (Based on camera metadata):
CCTV: Person (Hat, Top Clothing Color, Bottom Clothing Color), Vehicle (Vehicle Type), Face (Gender, Age, Mask, Cap, Glasses);
LPR: Vehicle (Color, Vehicle Type, Brand, Speed, Direction), License Plate (Number, Color, Country, Plate Type) |
| Application |
| Nx Witness Server | Support (Include Plug-in) |
| ONVIF Device | Support |
| Management |
| Web Management | Support |
| Web File Manager | Support |
| Basic Event | Audio Alarm, Network Disconnected, IP Address Conflict, SSD Full, SSD Uninitialized, SSD Error, No SSD, Low Voltage |
| Maintenance | Firmware Upgrade, Auto Reboot |
| Interface |
| Ethernet | 2*2500Mbps RJ45 Ethernet Port, Lan 1 support POE PD |
| Link Aggregation | Active Backup, Link Aggregation Control Protocol (LACP), and Adaptive Load Balancing (ALB) |
| Display | 2* HDMI Port;
Simultaneous Mode (Simultaneously outputs video sources for HDMI 1 & 2 ports)
HDMI 1 & 2: 3840x2160/60Hz, 1920x1080/60Hz |
| Audio | 1x 3.5mm Headphone Jack with Microphone Input (4-pole, TRRS, CTIA Standard) |
| Alarm I/O | 4/2 |
| Indicator light | 2 (Power & Alarm Light) |
| Reset Button | Yes |
| USB Interface | 2*USB 3.0 |
| Power Supply | PoE+ (802.3at) / DC 12V±15% (5525 DC power plug) |
| General |
| Consumption | Typical: 6W (Without SSD, DC), 8W (Without SSD, POE)
MAX: 16W (With 2*SSD, DC), 18W (With 2*SSD, POE) |
| Working Temperature | -20°C to 60°C |
| Working Humidity | 10% to 90% RH (No freezing and no condensation) |
| Cooling System | Fanless Design |
| Dimension | 135mm(W) X 140mm(D) X 40mm(H) |
| Installation | DIN Rail Mount, VESA Mount, Bracket Mount |
| Net Weight | 0.99 Kg |
| Package Weight | 1.3 Kg |
| Warranty | 3 Years |
